Table 31. Parts listing, 5U server model with hot-swap power supplies (continued)
Index
number Description of server component
CRU part
number (Tier 1)
CRU part
number (Tier 2)
60A 3 Phase PDU 46W1612
60A 3 Phase PDU 46W1614
NEMA PDU 39Y8913
IEC Rack PDU 39Y8914
DPI FE PDU 39Y8916
Half high LTO Gen 4 SAS tape drive 46X5672
Half high LTO Gen 5 SAS tape drive 46X5683
Drive, 5.25-inch, 80 GB, USB 99Y3870
Mouse, USB 39Y9875
Thermal solution fan kit for 5U chassis 00AL001
USB cable holder for 5U chassis 00AL692
Operating temperature enhancement kit for 5U chassis 00AL721
Miscellaneous hardware 00AL703
Consumable parts (parts that are purchased separately) are not covered by the IBM
Statement of Limited Warranty. The following consumable parts are available for
purchase from the retail store.
Index Description Part number
Battery, ServeRAID-M5100
series
81Y4491
Structural parts
Structural parts are not covered by the IBM Statement of Limited Warranty. You
can place an order on the structural parts from the IBM retail store.
The following structural parts are for 4U server models with non-hot-swap power
supplies. They are available for purchase from the retail store.
Table 32. Structural parts for 4U server models with non-hot-swap power supplies, Type 5457
Index Description Part number
1 Side cover assembly 00AL701
8 Air baffle 00AL109
9 4U chassis assembly 00AL700
12 Bezel 13N2450
12 Bezel 00AL690
Simple-swap hard disk drive cage, 3.5" drives 00AL689
Filler, power supply 00D8860
Filler, DVD-ROM Drive 13N2450
Feet, chassis 13N2985
EMC shield kit, optical disk drive/tape drive 13N2997
Kit, Retainer (for optical and diskette drives) 39R9369
174 System x3100 M5 Type 5457: Installation and Service Guide
