Server components
The section shows the major components in the server.
The following illustration shows the server components in 4U server models with
non-hot-swap power supplies. The illustrations in this document might differ
slightly from your hardware.
The following illustration shows the server components in 5U server models with
hot-swap power supplies. The illustrations in this document might differ slightly
from your hardware.
4U chassis
assembly
Side cover
assembly
Microprocessor
Heat
sink
Power
supply
(fixed)
Memory
Hard disk
drive
System fan (rear)
DVD-ROM
drive
Bezel
Air baffle
Front USB connector
assembly
Operator information
panel assembly
System
board
Figure 12. Server components for 4U server models with non-hot-swap power supplies
Chapter 2. Installing optional devices 29
