Table 30. Parts listing, 4U server model with non-hot-swap power supplies (continued)
Index
number Description of server component
CRU part
number (Tier 1)
CRU part
number (Tier 2)
Emulex 8Gb FC Single-port HBA 42D0491
Emulex 8Gb FC Dual-port HBA 42D0500
Emulex 16Gb FC Dual-port HBA 00D8548
QLogic 10Gb virtual fabric and SR optical transceiver 42C1816
Internal USB 3 RDX carrier/dock 46C2346
Internal USB RDX carrier/dock 46C5380
RDX 320 GB cartridge 46C5394
RDX 500 GB cartridge 46C5395
RSPDU+ 24C13 30A 46W1562
RSPDU 24C13 3P 46W1568
RSPDU 24C13 1P 46W1570
RSPDU+ 12C19/1 46W1574
RSPDU 12C19/12 46W1578
RPDU+ 9C19/3C1 46W1582
60A 3 Phase PDU 46W1612
60A 3 Phase PDU 46W1614
NEMA PDU 39Y8913
IEC Rack PDU 39Y8914
DPI FE PDU 39Y8916
Half high LTO Gen 4 SAS tape drive 46X5672
Half high LTO Gen 5 SAS tape drive 46X5683
Drive, 5.25-inch, 80 GB, USB 99Y3870
Mouse, USB 39Y9875
Thermal solution fan kit for 4U chassis 00AL719
USB cable holder for 4U chassis 00AL691
Operating temperature enhancement kit for 4U chassis 00AL720
3.5" simple-swap hardware RAID upgrade kit 00Y8280
Miscellaneous hardware 00AL703
Consumable parts (parts that are purchased separately) are not covered by the IBM
Statement of Limited Warranty. The following consumable parts are available for
purchase from the retail store.
Index Description Part number
Battery, ServeRAID-M5100
series
81Y4491
The following illustration shows the major components in the 5U server model
with hot-swap power supplies. The illustrations in this document might differ
slightly from your hardware. For 4U server models with non-hot-swap power
Chapter 5. Parts listing, IBM System x3100 M5 Type 5457 169
