12. Lift the hard disk drive cage out of the chassis.
Note: You may need to slightly twist and turn the hard disk drive cage in
order to remove it from the server.
Screws
Figure 94. Hard disk drive cage screw removal for 5U server model with hot-swap power
supplies
Hard disk Cage
Figure 95. Hard disk drive cage removal for 5U server model with hot-swap power supplies
Chapter 6. Removing and replacing components 195
