IBM x3100 M5 Type 5457 User Manual

The following figure shows the locations of the eight 2.5" hot-swap hard disk drive
bays in the 5U server model with hot-swap power supplies.
Bay 1
Bay 2
Bay 3
Bay 4
Bay 5
Bay 6
Figure 106. Location of the four 3.5" simple-swap hard disk drive bays in the 4U server
model with non-hot-swap power supplies
Bay 1
Bay 2
Bay 4
Bay 5
Bay 6
Bay 7
Bay 8
Bay 3
Bay 9
Bay 10
Figure 107. Location of the eight 2.5" hot-swap hard disk drive bays in the 5U server model
with hot-swap power supplies
202 System x3100 M5 Type 5457: Installation and Service Guide
