10-8
10
SET MODE
Item
Range or Value
(Default is shown in bold)
Descriptions Refer
MIC UP/DOWN SPEED HI (faster) or Lo (slower)
Sets the rate at which frequencies are
scanned when the microphone [UP]/[DN]
keys are held down.
p. 10-13
SSB/CW SYNCHRONOUS
TUNING
on or oF
Turns the displayed frequency shift function
ON or OFF.
p. 10-14
CW NORMAL SIDE L (LSB) or U (USB)
Select the carrier point of CW mode be-
tween LSB and USB.
BREAK-IN
oF (OFF), SE (Semi) or
FL (Full)
Selects the CW break-in type.
BREAK-IN DELAY
0.2 ~ 7.5 ~ 13.0 (dots), in
0.1 dots steps
Sets the break-in delay time for CW semi
break-in operation.
DOT/DASH RATIO
1:1:2.8 ~ 1:1:3.0 ~ 1:1:4.5,
in 0.1 unit steps.
Sets the internal electronic keyer dot/dash
ratio.
p. 10-15
PADDLE POLARITY n (Normal) or r (Reverse) Sets the paddle polarity.
KEYER TYPE
EL (ELEC-KEY),
bG (BUG-KEY) or
St (Straight key)
Selects the keyer type for the [KEY] con-
nector on the rear panel.
MIC UP/DOWN KEYER on or oF
Sets the activation of the microphone [UP]/
[DN] switches as a paddle.
MODE SELECT (SSB) on or oF
Turns the SSB (LSB/USB) mode selection
ON or OFF.
p. 10-16
MODE SELECT (CW) on or oF
Turns the CW/CW-R mode selection ON or
OFF.
MODE SELECT (RTTY) on or oF
Turns the RTTY/RTTY-R mode selection
ON or OFF.
MODE SELECT (AM) on or oF Turns the AM mode selection ON or OFF.
CI-V BAUD RATE
300, 1200, 4800, 9600,
19200 bps or Auto.
Sets the CI-V data transfer rate.
CI-V ADDRESS 76h Sets the CI-V address.
CI-V TRANSCEIVE on or oF
Turn the CI-V Transceive function ON or
OFF.
p. 10-17
REFERENCE FREQUEN-
CY ADJUSTMENT
0 ~ 100%, in 1% steps
( Default setting is different
for each transceiver.)
Sets the internal reference signal frequen-
cy.
Items in the Set mode (Continued) ■
