CONTROL COMMAND
Cmd. Sub cmd. Data
Description
1A 0343 0 Send/read MIC UP/DOWN keyer (HM-
36) OFF
1 Send/read MIC UP/DOWN keyer (HM-
36) ON
0344 0 Send/read SSB mode selection OFF
(inhibition)
1 Send/read SSB mode selection ON
(selectable)
0345 0 Send/read CW mode selection OFF
(inhibition)
1 Send/read CW mode selection ON (se-
lectable)
0346 0 Send/read RTTY mode selection OFF
(inhibition)
1 Send/read RTTY mode selection ON
(selectable)
0347 0 Send/read AM mode selection OFF (in-
hibition)
1 Send/read AM mode selection ON (se-
lectable)
0348 0 Send/read CI-V transceive function
OFF
1 Send/read CI-V transceive function ON
0349 0 to 255 Send/read reference frequency set
(0=0% to 255=100%)
0350 0 to 255 Send/read noise blanker level set
(0=0% to 255=100%)
0351 0 to 255 Send/read noise blanker width set
(0=0% to 255=100%)
0352 0 to 15 Send/read NR level set
(0=0 to 15=15)
0353 0 to 255 Send/read VOX gain set
(0=0% to 255=100%)
0354 0 to 255 Send/read Anti-VOX gain set
(0=0%, 255=100%)
0355 0 to 20 Send/read VOX delay set
(0=0.0 sec. to 20=2.0 sec.)
0356 0 to 10 Send/read speech compressor level
(0=0 to 10=10)
04 — Send/read DATA mode with filter set
(see to the right for detail)
05 0 Send/read Sharp selection for DSP fil-
ter shape
1 Send/read Soft selection for DSP filter
shape
06 0 Send/read manual notch width Wide
1 Send/read manual notch width Mid
2 Send/read manual notch width Narrow
1C 00 0 Send/read the transceiver’s status RX
1 Send/read the transceiver’s status TX
01 0 Antenna tuner OFF (through)
1 Send/read Antenna tuner ON
2 Send/read Manual tuning selection
D Band stacking register
Command: 1A 01
To send or read the desired band stacking register’s
contents, a combination of the frequency band and the
register codes (“01” is fixed as the register code) as
follows are used.
For example, when sending/reading the contents in
the 21 MHz band, the code “0701” is used.
• Frequency band codes
CODE BAND FREQUENCY RANGE
01 1.8 MHz
1.800000 – 1.999999
02 3.5 MHz
3.400000 – 4.099999
03 7 MHz
6.900000 – 7.499999
04 10 MHz
9.900000 – 10.499999
05 14 MHz
13.900000 – 14.499999
06 18 MHz
17.900000 – 18.499999
07 21 MHz
20.900000 – 21.499999
08 24 MHz
24.400000 – 25.099999
09 28 MHz
28.000000 – 29.999999
10 50 MHz
50.000000 – 54.000000
11 General
Other than above
D Data mode with filter width setting
Command: 1A 04
The following data sequence is used when sending or
reading the data mode with filter width setting.
XXXX
00=Data mode OFF
01=Data mode ON
00=Data mode OFF
01=FILTER Wide
02=FILTER Mid
03=FILTER Narrow
Second parameterFirst parameter
wq
Controlling the radio with CI-V ■
Command table (Continued) D
