Icom IC-7200

7-3
7
MEMORY OPERATION
You can program the Memory channels in either the
VFO mode or in the Memory mode.
D Programming in VFO mode
Push q
V/M
➔
to select the VFO mode.
Rotate w [DIAL] to set the desired frequency, and
then push
MODE
to set the operating mode.
Rotate e [M-CH] to select the desired memory chan-
nel.
• If the RIT control indicator lights orange, push
M-CH/RIT
SET
.
(p. 7-2)
• “ ” appears if the selected memory channel is a
blank channel (one without any stored data.)
Lower channels
Higher channels
RIT control indicator
goes out
Hold down r
MW
for 1 second to write the displayed
frequency and operating mode into the selected
memory channel.
• 3 beeps sound when memory writing is completed.
[EXAMPLE]:
Programming 7.088 MHz/LSB
into channel 12.
VFO mode
7.088 MHz/LSB are programmed into channel 12.
[EXAMPLE]:
Programming 7.088 MHz/LSB
into channel 12.
VFO mode
7.088 MHz/LSB are programmed into channel 12.
[EXAMPLE]:
Programming 7.088 MHz/LSB
into channel 12.
VFO mode
7.088 MHz/LSB are programmed into channel 12.
[EXAMPLE]:
Programming 7.088 MHz/LSB
into channel 12.
VFO mode
7.088 MHz/LSB are programmed into channel 12.
7.088 MHz/LSB
Hold down
MW
Rotate [M-CH]
[DIAL] [M-CH]
■ Programming memory channels
