PANEL DESCRIPTION
i7200
MODE
TUNER
TS
FILTER
SPCH
V/M A/B
SPLIT
M-CL
SCAN
SET
ATT
P . AMP
COMP VOX
MNF
RIT
1
23
456
7
8
0
50
28
1814
10
21
24
=
7
3.51.8
F-INP
M-CH/RIT
ENT
BAND
GENE
9
.
AGC
MW
ANF
METER
NRNB
V/M A/B
SPLIT
M-CL
SCANCOMP
VOX
MNF
RIT
1
23
456
7
8
0
50
28
1814
10
21
24
=
7
3.51.8
F-INP ENT
BAND
GENE
9
.
AGC
MW
@4@3@2
@5
D Keypad
@2 VFO/MEMORY/1/1.8 MHz BAND KEY
V/M
➔
Push to toggle the operating mode between the ➥
VFO mode and the memory mode. (pp. 3-3, 7-2)
Hold down for 1 second to copy the memory con- ➥
tents to the VFO. (p. 7-5)
1
1.8
Push ➥
F-INP ENT
BAND
, then push this key to input the
number ‘1.’ (p. 3-6)
Hold down ➥
F-INP ENT
BAND
for 1 second, then push this
key to select the 1.8 MHz band. (p. 3-4)
@3 VFO SELECT/EQUALIZATION/2/3.5 MHz BAND KEY
A/B
=
Push to toggle between VFO A and VFO B. ➥
(p. 3-2)
Hold down for 1 second to equalize the frequency ➥
and operating mode of the two VFOs. (p. 3-2)
• The undisplayed VFO frequency and operating mode
are set to the same frequency and operating mode
as the displayed VFO.
2
3.5
Push ➥
F-INP ENT
BAND
, then push this key to input the
number ‘2.’ (p. 3-6)
Hold down ➥
F-INP ENT
BAND
for 1 second, then push this
key to select the 3.5 MHz band. (p. 3-4)
@4 SPLIT/3/7 MHz BAND KEY
SPLIT
➥ Push to turn the Split function ON or OFF. (p. 6-8)
• “ ” appears when the split function is ON.

➥ Hold down for 1 second to activate the Quick split func-
tion.
(p. 6-10)
• VFO B’s frequency and operating mode are set to the
same frequency and operating mode as VFO A.
• The quick split function can be disabled in the Set
mode. (p. 10-10)
3
7
Push ➥
F-INP ENT
BAND
, then push this key to input the
number ‘3.’ (p. 3-6)
Hold down ➥
F-INP ENT
BAND
for 1 second, then push this
key to select the 7 MHz band. (p. 3-4)
@5 MEMORY WRITE/4/10 MHz BAND KEY
MW
Hold down for 1 second to store the displayed VFO
frequency and operating mode into the selected
memory channel. (p. 7-3, 7-4)
4
10
Push ➥
F-INP ENT
BAND
, then push this key to input the
number ‘4.’ (p. 3-6)
Hold down ➥
F-INP ENT
BAND
for 1 second, then push this
key to select the 10 MHz band. (p. 3-4)
