Icom IC-7200

4-7
4
RECEIVE AND TRANSMIT
Operating in the CW mode ■
Convenient functions for receiving (Continued) D
• Manual notch lter (p. 5-10)
Push ➥
MNF
to turn the manual notch filter ON or
OFF.
• “ ” appears when the manual notch filter is ON.
Hold down ➥
MNF
for 1 second to enter the manual
notch filter Set mode, then rotate [DIAL] to select
the narrow, mid or wide filter width.
• ¼ function (p. 10-13)
Hold down q
M-CH/RIT
SET
for 1 second twice to enter the
Set mode.
Rotate w [M-CH] to select “DIAL ¼”.
Rotate e [DIAL] to turn the
1
⁄4 function ON or OFF.
Push r
M-CH/RIT
SET
to exit the Set mode.
• CW tone pitch control (p. 10-5)
Hold down q
M-CH/RIT
SET
for 1 second to enter the Quick
Set mode.
Rotate w [M-CH] to select “CW PITCH”.
Rotate e [DIAL] to set the desired CW tone pitch to
between 300 to 900 Hz, in 10 Hz steps.
Push r
M-CH/RIT
SET
to exit the Quick Set mode.
[DIAL]
[DIAL] [M-CH]
[DIAL] [M-CH]
• Break-in function (p. 6-4)
Hold down q
M-CH/RIT
SET
for 1 second twice to enter the
Set mode.
Rotate w [M-CH] to select “BK-IN”.
Rotate e [DIAL] to set the CW break-in to full break-
in, semi break-in or OFF.
• FL : Full break-in
• SE : Semi break-in
• OF : Break-in OFF
Push r
M-CH/RIT
SET
to exit the Set mode.
• Keying speed setting (p. 10-5)
Hold down q
M-CH/RIT
SET
for 1 second to enter the Quick
Set mode.
Rotate w [M-CH] to select “KEY SPD”.
Rotate e [DIAL] to set the CW key speed to between
6 and 60 wpm.
Push r
M-CH/RIT
SET
to exit the Quick Set mode.
D Convenient functions for transmit
[DIAL] [M-CH]
