Icom IC-7200

6-5
6
FUNCTIONS FOR TRANSMIT
Break-in function (Continued) ■
D Full break-in operation
In full break-in, the transceiver automatically switches
to receive between keying dots and dashes so that
the operator can hear activity on the frequency.
Push q
MODE
to select the CW or CW-R mode.
• Hold down
MODE
for 1 second to toggle between the
CW and CW-R modes.
w Set the full break-in mode to ON in the Set mode.
(See below)
“ e F-BK” appears on the LCD.
When using a paddle, set “KEY SPD” in the Quick
Set mode to adjust the keying speed. (p. 10-5)
q Hold down
M-CH/RIT
SET
for 1 second twice to en-
ter the Set mode.
w Rotate [M-CH] to select “BK-IN” to set the CW
break-in mode.
e Rotate [DIAL] to select “FL.”
• FL : Full break-in
• SE : Semi break-in
• OF : Break-in OFF
r Push
M-CH/RIT
SET
to exit the Set mode.
[DIAL] [M-CH]
Appears
[DIAL]
[M-CH]
Appears
Full break-in operation
