Chapter 7
Cable Testing Fundamentals
7-8
Problem: Miswired pins
Probable Causes Conductors reversed at a connector.
Other Tests Affected Test Possible Result
Usually none Infrequently, one or more tests may
fail.
Wire Length Test
This test measures the length of each wire pair to make sure that the recommended
limits for the particular cable type are not exceeded. Depending on the units
selected in the Setup menu, length is reported in either feet or meters. See Chapter
3, Setup information.
Note: The RH is not required to perform this test.
To Next Page
