Table 2-5: Remote Handset (RH) Keys, LED, and Connectors
Item RH Front Panel Description
1 B/W LCD Two line alphanumeric display
2 Hazard LED Excessive line voltage present (TELCO)
3 Pass LED Successful test results
4 Fail LED Unsuccessful test result(s)
5 On LED RH unit on
6 Autotest Key Press to activate Autotest
7 Escape Key Abort and exit the current activity without making
change.
8 Tone Key Press to activate/deactivate Tone
9 Talk Key Press to activate/deactivate Talkset
10 Shift Key Toggle key activities having dual functions
11 Backlight Key Toggle the screen backlight on/off
12 On/Off Switch Power the Remote Handset on/off
13
Low-Crosstalk Connector
Port
Test access cable connector
14 Talkset Jack Connect a Talkset headset and microphone
15 DC Input Jack Connect an external power supply
16 DB-9 Serial Port Interface to a PC or serial printer
17 USB Port Interface to a PC
