2-15
The Remote Handset
The RH (Remote Handset) works with the DH (Display Handset) to perform
Autotest or individual real time Analyze tests. The RH terminates the cable link
and communicates with the DH. The RH is automatically activated by the DH.
The RH needs to have power available when performing a field calibration,
otherwise, the DH will not find it.
Display, Controls, Indicators, and Interface
Figure 2-6 shows the controls and indicators of the Remote Handset (RH).
Table 2-7 provides a brief description of each RH feature.
Figure 2-6: Remote Handset (RH)
