Appendix D
Model Features, Options, Accessories, and Specifications
D-3
Environmental and Physical Specifications
The following environmental specifications apply to all LANTEK Cable Testers.
LANTEK 6 Specifications
Range Resolution Accuracy
Length (50 0r 100 Ω Cable)
0-2000 ft 1 ft +(3% + 3 ft)
Delay 0-8000 ns 1 ns +(3% + 1 ns)
Average Impedance
35-180 Ω 0.1 Ω +(3% + 1 Ω)
Capacitance (Bulk) 0-100 nF 1 pF or 3 dig +(2% + 20 pF)
Capacitance 0-100pF/ft 0.1 pF +(2% + 1 pF)
DC Loop Resistance
0-200 Ω 0.1 Ω +(1% + 2 Ω)
Attenuation 1-350 MHz 0.1 dB Level III*
NEXT 1-350 MHz 0.1 dB Level III*
Return Loss 1-350 MHz 0.1 dB Level III*
ELFEXT 1-350 MHz 0.1 dB Level III*
Noise Floor >-90 dB
Dynamic Range < 90 dB
* Level III only specified to 250 MHz
Storage Capacity (Internal Memory)
Cat 5e, 6 (No Graphics) 6,000 Test Results
Cat 5e with Graphics 100 Test Results
Cat 6 with Graphics 60 Test Results
Storage Capacity (External 32MB Flash)
Cat 5e, 6 (No Graphics) 24,000 Test Results
Cat 5e with Graphics 400 Test Results
Cat 6 with Graphics 240 Test Results
