Chapter 6
Using LANTEK REPORTER
6-8
3. Click on the Options menu and select the Serial Port command. Select the
correct Port and match the Baud Rate to that of your LANTEK tester.
4. After you have entered the values, click the Test button. If the Tester is
identified, its serial and model numbers will be displayed.
5. Click OK.
Note: If you have tried alternative baud rates and ports and LANTEK Reporter still cannot
find the Tester, call IDEAL INDUSTRIES Customer Support.
LANTEK Reporter User Interface
The Menu Bar
The menu bar at the top of the screen displays the pull-down menu names.
When you choose a menu, a list of commands drops down under the menu. You
can choose only the commands that are solid black. Gray commands or options are
disabled or may be context-sensitive. For example, to use test commands such as
Find Test and Select Test, the cursor must be in the test grid portion of the screen
or the commands are not available.
To open a menu
1. Move the mouse so that the tip of the mouse pointer is on the desired menu.
2. Click the left mouse button, or press and hold the Alt key and then the
underlined letter in the menu name.
