Chapter 3
Calibration, Configuration, and Special Operations
3-27
Simple Cable ID/AutoName Option
Cable IDs and Test Numbering
Single and Double Cable IDs
There are two levels of AutoName capability: Single and Double ID. The Double
ID feature has several benefits:
• Both ends of the cable under test are clearly identified.
• While reviewing saved test records, potential problems can be identified and
quickly located.
If the Autosave Autotest preference is selected, names will automatically be
assigned to completed tests.
• You can assign a maximum of two unique 10-character cable names for the
cable under test (Double ID).
• The tester defaults to a single naming mode (Single ID). The following three
screens are examples of unique Single and Double Cable IDs.
1. Single ID Example
A unique alphanumeric
character name can be entered,
along with a four-character
incrementing counter field. The
counter is set by default or by
the user. This example is set to
start at 0003.
