Chapter 2
Your Cable Tester
2-14
Removable Mass Storage
The LANTEK tester provides two PCMCIA slots (Slot 0/Slot 1) for compact flash
memory. These external memory modules can be used for storing test results.
Storage will be organized in a standard Windows file structure with folders
having names corresponding to job names and containing the test’s data files.
Figure 2-4: PCMCIA Slots
The storage system can accommodate compact flash memory up to 256 MB. The
firmware will automatically present the option of moving test data from the
internal memory to the Compact Flash, if the flash card is installed. The stored
test data from the flash card can be transferred to a PC or laptop through the use
of a flash card reader.
Figure 2-5: PCMCIA Adapter, Compact Flash Card and Reader
