Chapter 3
Calibration, Configuration, and Special Operations
3-13
Setting Autotest Preferences
Autotest can be set to automatically stop on the first failed test, as well as to print,
save, and name test results at the completion of each test series.
Table 3-4: Autotest Preference Options
Option Action
Simple Cable ID Assigns a fixed alpha value for the Cable ID.
Pass/Fail Icon Display Pass or Fail icon for overall test and individual test.
Stop on Fail Autotest aborts at the first failed test. Otherwise, Autotest continues
until all tests are completed, regardless of results.
Note: If a wire map cannot be reliably completed due to gross
miswiring, the Autotest may abort regardless of the setting of
this preference.
AutoSave Autotest automatically names and saves any passed Autotest results.
Failed tests are not automatically saved.
Save Graphs Displaying graphs on the DH requires data to be transferred from
the RH to the DH. To save time during testing, do not select this
option.
Auto Increment Autotest automatically increments the Single and Double Cable ID
test counters.
Marginal
Pass/Fail
Display Pass or Fail with an * identifying marginally effected test(s).
ACR Perform ACR Test.
Resistance Perform Resistance Test.
Impedance Perform Impedance Test.
Enable 24
ELFEXT
Enable measurements at the DH for all possible pair combinations.
