IDEAL INDUSTRIES LANTEK User Manual

Appendix C
Measurement Methods and Limits
C-8
EINBETTENEINBETTENEINBETTENEINBETTENPower Sum
ACR (ANSI/TIA/EIA)
ANSI/TIA/EIA
Frequency
(MHz/dB)
Permanent
Channel
Permanent
Channel
Permanent
Channel
Permanent
Channel
1.00 54.90 54.80 71.20 70.30
2.00 - -
3.00 - -
4.00 48.00 46.40 61.80 60.50
8.00 41.40 39.40 57.00 55.60
10.00 39.30 37.00 55.50 54.00
16.00 34.00 31.50 52.20 50.60
20.00 31.50 28.80 50.70 49.00
25.00 28.80 25.90 49.10 47.30
31.25 26.00 22.80 47.50 45.70
62.50 15.90 12.00 42.70 40.60
100.00 7.70 3.10 39.30 37.10
125.00 37.70 35.40
155.52 36.10 33.80
175.00 35.30 32.90
200.00 34.30 31.90
250.00
32.70
30.20
Category 3 Category 5 Category 5e Category 6 (Draft 9)
ANSI/TIA/EIA568/TSB67 ANSI/TIA/EIA568/TSB67/95 ANSI/TIA/EIA568/TSB67/95
ANSI/TIA/EIA568
