Appendix C
Measurement Methods and Limits
C-11
EINBETTENPower Sum ELFEXT (ANSI/TIA/EIA)
ANSI/TIA/EIA
Frequency
(MHz/dB)
1.00 54.90 54.80 61.20 60.30
2.00 - - - -
3.00 - - - -
4.00 48.00 46.40 49.10 48.20
8.00 41.40 39.40 - -
10.00 39.30 37.00 - -
16.00 34.00 31.50 37.10 36.20
20.00 31.50 28.80 35.10 34.20
25.00 28.80 25.90 33.20 32.30
31.25 26.00 22.80 31.40 30.40
62.50 15.90 12.00 25.30 24.40
100.00 7.70 3.10 21.20 20.30
200.00 15.20 14.20
250.00 13.20 12.30
ANSI/TIA/EIA568/TSB67 ANSI/TIA/EIA568/TSB67/95 ANSI/TIA/EIA568/TSB67/95 ANSI/TIA/EIA568
Category 3 Category 5 Category 5e Category 6 (Draft 9)
ISO
Frequency
(MHz/dB)
2.00 - -
3.00 - -
4.00 45.00 42.40 49.10 48.20
8.00 39.00 36.00 43.10 42.20
10.00 37.00 34.40 41.20 40.20
16.00 32.90 30.30 37.10 36.10
20.00 31.00 28.40 35.10 34.20
25.00 29.00 26.50 33.20 32.30
31.25 27.10 24.50 31.30 30.30
62.50 21.10 18.50 25.20 24.30
100.00 17.00 14.40 21.20 20.20
125.00 19.20 18.30
155.52 17.30 16.40
175.00 16.30 15.40
200.00 15.10 14.50
250.00 13.20 12.30
ISO Class-D 11801 Proposed
ISO Class-C AS/NZS 3080 ISO Class-D ISO Class-E
