IDEAL INDUSTRIES LANTEK User Manual

Chapter 2
Your Cable Tester
2-4
NEXT
Frequency Range
Measurement Range
Dynamic Range
Frequency Step Size (kHz)
Residual NEXT
Resolution
Accuracy
1 - 350 MHz (LANTEK 6)
1 - 750 MHz (LANTEK 7)
20 – 100dB
70dB to 700 MHz
150,250,500,1000
72dB
0.1dB
Exceeds Level III
Return Loss
Frequency Range
Measurement Range
Frequency Step Size (kHz)
Resolution
Accuracy
1 - 350 MHz (LANTEK 6)
1 - 750 MHz (LANTEK 7)
0 – 30dB
150,250,500,1000
0.1dB
Exceeds Level III
Auto Test Time
Cat 5-E
Cat 6
Certification to 750 MHz
(LANTEK 7 only)
<25 seconds
<30 seconds
<35 seconds
Average Noise
Range
Bandwidth
Resolution
Accuracy
0 – 2Vrms
40 – 500 Hz
10mVrms
+(3% +20mVrms)
