Chapter 3
Calibration, Configuration, and Special Operations
3-6
Calibration
Calibration is performed with the Channel adapters and patchcords. The Reference
Patchcords supplied have plugs that match the jacks in the Channel adapters. We
recommend that you calibrate with the patchcords that will be used for Permanent
Link Testing. These cords should be identical, good quality, shielded patchcords.
Once the calibration is complete, the information is retained by the test unit to
disclose the characteristics of the mated pair used to connect the patchcord cable
to the test adapter.
Performing a Permanent Link Test
1. Insert one end of a patchcord into the adapter’s jack at both the Near-End
and the Far-End.
2. Insert the other end into the Permanent Link’s jack at both the Near-End and
the Far-End.
3. Select the appropriate Permanent Link Test.
4. Start the Autotest Function.
