25: D
ATA
L
OG
I
NSTRUCTIONS
25-18 FC6A S
ERIES
MICROS
MART
L
ADDER
P
ROGRAMMING
M
ANUAL
FC9Y-B1726
5. Tag Name
Enter tag names or device addresses to specify the devices to the CSV files.
6. Device Address
When the devices are specified as tag names, the corresponding device addresses are shown.
7. Display Type
Select the display type from the following table for each device for when the device values are output to the CSV file.
8. Repeat
The data in as many consecutive devices as the specified repeat, starting from the specified device address, are output to the
SD memory card.
For example, when the display type of D10 is DEC(W) and the repeat is set to 8, the data is output to SD memory card as
follows.
9. Trace data size
The amount of memory that the TRACE instruction uses for the current trace settings is shown. The amount of memory used
increases when a device to trace the data is added. You can register up to a maximum of 64 devices (the total amount of
memory must be less than or equal to 1,024 bytes). One byte of memory area is required for each character.
10. Remaining size
The amount of free memory (the difference between the trace data size and 1,024 bytes) is shown.
11. The number of scans
How many scans of trace data can be accumulated with the current trace settings is shown. The number of scans of data that
can be accumulated depends on the format of the trace data to output. If there is little data to output per scan, the data for
many scans can be accumulated.
Display Type Range Maximum Characters
Decimal (W) 0 to 65,535 5
Decimal (I) -32,768 to 32,767 6
Decimal (D) 0 to 4,294,967,295 10
Decimal (L) -2,147,483,648 to 2,147,483,647 11
Decimal (F) -3.402823E+38 to 3.402823E+38 13
Hexadecimal (W) 0000 to FFFF 4
Hexadecimal (D) 00000000 to FFFFFFFF 8
Binary (B) 0 or 1 1
Triggered at: 2015/12/30 15:40:30 Header row 1
Scan D0010 D0011 D0012 D0013 D0014 D0015 D0016 D0017 Header row 2
Old 1 9 172533414957 Data 7 scans before
2 10182634425058 Data 6 scans before
3 11192735435159 Data 5 scans before
4 12202836445260 Data 4 scans before
5 13212937455361 Data 3 scans before
6 14223038465462 Data 2 scans before
7 15233139475563 Data 1 scan before
New 8 16 24 32 40 48 56 64 Latest data
