FC6A S
ERIES
MICROS
MART
L
ADDER
P
ROGRAMMING
M
ANUAL
FC9Y-B1726 25-19
25: D
ATA
L
OG
I
NSTRUCTIONS
CSV File Output Format and File Format Configuration
• Output format
The CSV file output format is as follows.
When the TRACE instruction is executed and the CSV file for the same date does not exist in the folder designated by S1, a new
CSV file is created and the trace data is output as shown in above output format example. When the date changes and the TRACE
instruction is executed, a new CSV file is created with a new file name.
• File format
The decimal symbol and separating character in CSV files can be specified in the function area settings. For details, see Chapter 11
"SD Memory Card" in the
"FC6A Series MICROSmart User’s Manual".
Examples: TRACE
When M0 is turned on, the accumulated data of D0 through D5 (data type W (word)) and D10 (data type F (floating point)) are
saved as decimal values in a CSV file on the "RESULT" folder on the SD memory card.
Output sample
The sample user program described below operates as follows.
• M100 is turned on when the writing trace data to the SD memory card completes.
• The TRACE instruction status code is stored to D100.
• The execution status saved in D100 is checked and Q0 is turned on if an error occurs.
ï½¥
ï½¥
ï½¥
Triggered at:,2015/12/30 15:40:30
Scan,D0010,D0020,D0030,D0040,D0050,D0060,D0070,D0080
Old,1,9,17,25,33,41,49,57
,2,10,18,26,34,42,50,58
,3,11,19,27,35,43,51,59
,4,12,20,28,36,44,52,60
,5,13,21,29,37,45,53,61
,6,14,22,30,38,46,54,62
,7,15,23,31,39,47,55,63
New,8,16,24,32,40,48,56,64
Triggered at: 2012/02/06 10:20:30
Scan D0000 D0001 D0002 D0003 D0004 D0005 D0010
Old 12345 2 12345 56789 1 56789 -3.402823E+38
12345 2 12347 56789 1 56788 -3.402823E+38
12345 2 12349 56789 1 56787 -3.402823E+38
: : ::::: :
12345 2 12379 56789 1 56772 -3.402823E+38
12345 2 12381 56789 1 56771 -3.402823E+38
New 12345 2 12383 56789 1 56770 -3.402823E+38
