FC6A S
ERIES
MICROS
MART
L
ADDER
P
ROGRAMMING
M
ANUAL
FC9Y-B1726 26-9
26: S
CRIPT
7. Export
Click this button to display the Save As dialog box so you can export the script program.
If you select the location to save the script, enter a file name, and click Save, the current script is saved as a text file (*.txt). The
saved script can be inserted with Import.
8. Options
Click this button to display the Options dialog box.
In the Options dialog box, you can configure the font for the text used in the Script text box, the colors, the tab indents, and
other settings. For details, see "Script Formatting Options Dialog Box" on page 26-11.
9. Find
Click this button to display the Find dialog box.
You can search the entered text in the script.
Note: If you first select an area in the Script and then click Find, you can search only in the selected area.
10. Replace
Click this button to display the Replace dialog box.
Enter the text to search in the script in Find What and enter the text to replace it with in Replace With.
Notes:
• This is an effective tool when replacing device addresses.
• If you first select an area in the Script and then click Replace, you can search and replace text only in the selected area.
11. Show/Hide Function List
This button shows and hides Function List and Output.
Note: Click and drag the bottom right corner of Script Editor and you can change the size of the box for editing scripts. By hiding Function List and
Output, you can increase the size of the script editing area (text box) and make it easier to edit the script.
12. Cursor
Shows the current cursor position in the Script text box as the line number and the column number.
