REMOTE OPERATION
5-10 46882/439
Source selection
SOURCE
Select RF Source A, B or C as current source. When a source is selected, the
source-specific commands and queries will then apply to that source.
Data type :
Character Program Data (A, B or C)
Allowed suffices :
None
Default suffix :
None
SOURCE?
Prepares message containing information on the current RF Source selection
in the following format:
:SOURCE <mode>
where: <mode> is character program data indicating the current source
(A, B or C).
Example:
:SOURCE B
Combiner mode
CMODE
Set the combined output mode. The combinations are as follows:
(where A, B and C refer to sources A, B and C respectively)
A+B, B+C, A+C, A+B+C, A, B, C, OFF
Data type :
Character Program Data (A, B, C, AB, BC, AC, ABC, OFF)
Allowed suffices :
None
Default suffix :
None
Examples:
CMODE ABC
CMODE?
Prepares message containing information on the combined output mode
setting in the following format:
:CMODE <mode>
Example:
:CMODE ABC
Coupling (carrier frequency and RF level)
COUPLING
[not used alone]
:MODE
Set coupling mode
Data type :
Character Program Data (combinations of CFRQAB, CFRQAC, RFLVAB
and RFLVAC, or DISABLED. See table below.)
Allowed suffices :
None
Default suffix :
None
VALID COUPLING MODES
CFRQAB : Enable Carrier Frequency coupling between sources A and B.
CFRQAC : Enable Carrier Frequency coupling between sources A and C.
RFLVAB : Enable RF Level coupling between sources A and B.
RFLVAC : Enable RF Level coupling between sources A and C.
DISABLED : Disable all coupling.
Note: Order is not important, for example CFRQAC, RFLVAB is equivalent
to RFLVAB, CFRQAC.
:CFRQAB or :CFRQAC
:MODE
Select HARMonic or SUBHARMonic relationship
Data type :
Character Program Data (either HARM or SUBHARM))
