ACCEPTANCE TESTING
7-4 46882/439
Recommended test equipment
The test equipment recommended for acceptance testing is shown below. Alternative equipment
may be used provided it complies with the stated minimum specification.
Recommended test equipment
Description Minimum specification Example
Power meter
±0.1 dB from 10 kHz to 2.4 GHz
IFR
†
6960B with
6912 and 6932
Sensors
Measuring receiver
0 dBm to −127 dBm; 2.5 MHz to 2.4 GHz.
Capable of measuring residual FM <2 Hz and
SSB phase noise <−124 dBc/Hz at 20 kHz offset
from a 1 GHz carrier
Agilent 8902A with
Option 037* and
11722A Sensor and
11793A
Down-Converter
#
Signal generator +8 dBm from 32.5 MHz to 2.43 GHz
IFR
†
2041
Frequency counter 10 Hz to 2.4 GHz EIP 535B or
IFR
†
2440
Audio analyzer Capable of measuring THD of 0.01% from
100 Hz to 20 kHz
Rohde & Schwarz
UPA3
Spectrum analyzer DC to 7.2 GHz, 3 Hz resolution bandwidth Anritsu MS2602A or
IFR
†
2386
Modulation meter
AM, FM and ΦM 50 kHz to 2.4 GHz. Accuracy
±1% at 1 kHz modulation frequency
IFR
†
2305 plus
Distortion Option **
Function generator
DC to 100 kHz sine, ±0.6 dB flatness, 100 kHz
square wave
Agilent 3325B
Digital voltmeter DC voltage measurement Solartron 7150+
50 Ω load
(termination)
1 W, 50 Ω nominal impedance, DC to 2.4 GHz
Lucas Weinschel
M1404N
2-turn loop 25 mm diameter
Oscilloscope 100 MHz bandwidth Tektronix TAS 465
†
IFR Ltd. was previously known as Marconi Instruments Ltd.
* Option 037 is necessary to measure SSB phase noise.
#
If the receiver and down-converter are not available, an alternative procedure to ensure
attenuator pad accuracy using a power meter is given.
** The distortion option of the 2305 Modulation Meter allows modulation distortion tests to be
carried out with greater ease. If a 2305 with the distortion option is not available, the audio
analyzer may be connected to the modulation meter LF output and set to measure distortion.
