IFR 2026 User Manual

ACCEPTANCE TEST RESULTS TABLES
46882/439 7-51
Table 7-27 Sources A/C intermod test (Option 1 only)
RF level
(dBm)
Source A
frequency
(MHz)
Source C
frequency
(MHz)
Spacing
(kHz)
Lower IP
frequency
(MHz)
Upper IP
frequency
(MHz)
IP level
(dBc)
Result (dBc)
Upper Lower
0 5.001 5.008 7 4.994 5.015
−75
_____ _____
0 25.5 25.507 7 25.493 25.514
−80
_____ _____
0 800 800.007 7 799.993 800.014
−80
_____ _____
0 1000 1000.007 7 999.993 1000.014
−80
_____ _____
0 2000 2000.007 7 1999.993 2000.014
−80
_____ _____
0 2397 2397.007 7 2396.993 2397.014
−80
_____ _____
−14
5.001 5.008 7 4.994 5.015
−75
_____ _____
−14
25.5 25.507 7 25.493 25.514
−80
_____ _____
−14
800 800.007 7 799.993 800.014
−80
_____ _____
−14
1000 1000.007 7 999.993 1000.014
−80
_____ _____
−14
2000 2000.007 7 1999.993 2000.014
−80
_____ _____
−14
2397 2397.007 7 2396.993 2397.014
−80
_____ _____
Table 7-28 Sources B/C intermod test (Option 1 only)
RF level
(dBm)
Source B
frequency
(MHz)
Source C
frequency
(MHz)
Spacing
(kHz)
Lower IP
frequency
(MHz)
Upper IP
frequency
(MHz)
IP level
(dBc)
Result (dBc)
Upper Lower
0 5.001 5.008 7 4.994 5.015
−75
_____ _____
0 25.5 25.507 7 25.493 25.514
−80
_____ _____
0 800 800.007 7 799.993 800.014
−80
_____ _____
0 1000 1000.007 7 999.993 1000.014
−80
_____ _____
0 2000 2000.007 7 1999.993 2000.014
−80
_____ _____
0 2397 2397.007 7 2396.993 2397.014
−80
_____ _____
−14
5.001 5.008 7 4.994 5.015
−75
_____ _____
−14
25.5 25.507 7 25.493 25.514
−80
_____ _____
−14
800 800.007 7 799.993 800.014
−80
_____ _____
−14
1000 1000.007 7 999.993 1000.014
−80
_____ _____
−14
2000 2000.007 7 1999.993 2000.014
−80
_____ _____
−14
2397 2397.007 7 2396.993 2397.014
−80
_____ _____
