ACCEPTANCE TEST RESULTS TABLES
46882/439 7-61
Table 7-46 Pulse mod. RF output at +4 dBm
Carrier frequency
(MHz)
RF level min.
(dBm)
Result (dBm)
src A src B (src C)
RF level max.
(dBm)
32 +2.7 ____ ____ ____ +5.3
60 +2.7 ____ ____ ____ +5.3
180 +2.7 ____ ____ ____ +5.3
300 +2.7 ____ ____ ____ +5.3
420 +2.7 ____ ____ ____ +5.3
540 +2.7 ____ ____ ____ +5.3
660 +2.7 ____ ____ ____ +5.3
780 +2.7 ____ ____ ____ +5.3
900 +2.7 ____ ____ ____ +5.3
1020 +2.7 ____ ____ ____ +5.3
1140 +2.7 ____ ____ ____ +5.3
1200 +2.7 ____ ____ ____ +5.3
1201 +1.9 ____ ____ ____ +6.1
1260 +1.9 ____ ____ ____ +6.1
1380 +1.9 ____ ____ ____ +6.1
1500 +1.9 ____ ____ ____ +6.1
1620 +1.9 ____ ____ ____ +6.1
1740 +1.9 ____ ____ ____ +6.1
1860 +1.9 ____ ____ ____ +6.1
1980 +1.9 ____ ____ ____ +6.1
2220 +1.9 ____ ____ ____ +6.1
2340 +1.9 ____ ____ ____ +6.1
2400 +1.9 ____ ____ ____ +6.1
Table 7-47 Pulse modulation on/off ratio test
Carrier frequency
(MHz)
Pulse mod. on/off
ratio (dB)
Measured value (dB)
src A src B (src C)
32 >45 ____ ____ ____
100 >45 ____ ____ ____
320 >45 ____ ____ ____
1000 >45 ____ ____ ____
1200 >45 ____ ____ ____
1500 >40 ____ ____ ____
1800 >40 ____ ____ ____
2100 >40 ____ ____ ____
2400 >40 ____ ____ ____
