7.3 External Connections
7
SPECIFICATIONS
■
VF Connector
Used to connect a 2-inch viewnder.
1 2 3 4 5
6 7 8 9
10
11 12 13 14 15
16 17 18 19 20
Insertion Side
Camera head side : HR12-14RA-20SC
Receptacle
ecafretnI lanretxEO/InoitcnuFemaN.oN niP
①
+ 12 V
TUOylppus rewop V21+ CD
②
+ 12 V
TUOylppus rewop V21+ CD
③
N.C
―――――――――――――――――――――
④
+12V RET (VF GND)
Ground for DC+12V power supply RET
⑤
+12V RET (VF GND)
Ground for DC+12V power supply RET
⑥
G/Y VF VIDEO
TUOlangis tuptuo OEDIV FV Y/G
6
7
75
⑦
G/Y VF VIDEO RET
Ground for G/Y VF VIDEO output signal RET
⑧
VF M CLK
Reference clock pulse signal for serial data
reproduction
OUT
⑨
SP WR
Read pulse signal for serial-parallel data conversionOUT
⑩
VF SP DATA
Serial data signal for serial-parallel data conversionOUT
⑪
+12V RET
Ground for DC+12V power supplyRET
⑫
ZEBRA ON
ZEBRA signal ON/OFF switching IN
⑬
ZOOM POSI
TUOlortnoc noitisop mooZ
⑭
( +9V )
―――――――――――――――――――― ―
⑮
COLOR ON
NIlortnoc FV roloC
⑯
B VF VIDEO
TUOlangis tuptuo OEDIV FV B
16
17
75
⑰
B VF VIDEO RET
Ground for B VF VIDEO output signal RET
⑱
R VF VIDEO
TUOlangis tuptuo OEDIV FV R
18
19
75
⑲
R VF VIDEO RET
Ground for R VF VIDEO output signal RET
⑳
+12V RET
Ground for DC+12V power supply RET
