7.3 External Connections
7
SPECIFICATIONS
Pin No. Name Function I/O External Interface
○
43
IRIS FOLLOW SE
LENS IRIS control output in SE operation
F 2.8 : 6.2 V± 0.05 V
(6.2 V± 0.1 V)
F 16 : 3.4 V± 0.05 V
(3.4 V± 0.1 V)
CLOSE : 2.5 V± 0.2 V
(2.1 V to 2.9 V)
Zin = 100 kΩ± 2% (100 kΩ or more)
OUT
○
44
ZOOM FOLLOW SE
Lens zoom control output in SE operation
WIDE : 2.0 V± 0.05 V
(2.0 V± 0.2 V)
TELE : 7.0 V± 0.05 V
(7.0 V± 0.2 V)
Zin = 100 kΩ± 2% (10 kΩ or more)
Zout = 1 kΩ± 10% (1 kΩ or less)
OUT
○
45
N . C
(Unusable) ―
○
46
N . C
(Unusable) ―
○
47
N . C
(Unusable) ―
○
48
N . C
(Unusable) ―
○
49
N . C
(Unusable) ―
○
50
N . C
(Unusable) ―
