2.1 Camera and Viewfinder
①
Viewfinder (VF)
Displays camera image, return image, various characters and markers. 2" color viewnder
and 7" LCD studio viewnder (optional) can be used.
②
Handle
Grip this handle to carry the camera.
③
RET-2/MIC button
The RET-2 switch function or INTERCOM MIC switch function is allocated to this button.
The button selects the function or turns ON/OFF the function.
●
When set to RET-2
The viewnder image is switched from the camera image to RET-2 image while this
button is pressed.
●
When set to INTERCOM MIC
Turns the intercom microphone ON/OFF when the INTERCOM FRONT VR SELECT
switch on the rear of the camera is set to "ENG" or "PROD". The intercom microphone is
turned ON while this button is pressed.
④
RET-1 button
Switches the viewnder image from the camera image to RET-1 image. The viewnder
image is switched to the RET-1 image while this button is pressed.
⑤
Shoulder belt hook
Attaches an optional shoulder belt.
⑥
POWER indicator
Displays the status of power supply to the camera
Green LED : Indicates power is on
Red LED : Indicates power is in standby
⑦
POWER switch
Turns ON/OFF the power of the camera or switches the power supply.
CCU : Supplies power from the CCU to the camera via ber cable.
OFF : Turns power OFF.
EXT : Supplies power from external power supply. Set the POWER switch to EXT when
power is supplied from external AC adapter through DC IN connector in the self-
contained or VTR location operation.
⑧
Shoulder pad
Put the shoulder pad on your shoulder when you carry the camera on your shoulder.
⑨
INTERCOM MIC button
Turns the intercom microphone ON/OFF when the INTERCOM FRONT VR SELECT
switch on the rear of the camera is set to "ENG" or "PROD". The intercom microphone is
turned ON while this button is pressed.
⑩
INTERCOM PGM control knob
Controls the PGM volume of the intercom when the INTERCOM FRONT VR SELECT
switch on the rear of the camera is set to "ENG" or "PROD".
⑪
INTERCOM PHONE control knob
Controls the volume of the intercom when the INTERCOM FRONT VR SELECT switch on
the rear of the camera is set to "ENG" or "PROD".
⑫
Switch control panel cover
Protects the switch control panel.
Reference:
The functions are allocated
using the menu. Refer to
"5.
CAMERA SETTINGS and
ADJUSTMENT : Menu
Configuration and content"
(P85)
for setting.
