16
HDK-99 1803 VER1 (E)
2.1 Camera and Viewfinder
⑳
OUTPUT SELECT switch
Switches between the picture shot by the camera and the color-bar signal.
CAM : Outputs the picture shot by the camera.
BARS : Outputs the color-bar signal.
GAIN SELECT switch
Selects the gain of the camera.
O : Normally selected (0dB value).
M : Gain value set by the menu is obtained. The set value is -6dB, -3dB, +3dB, +6dB
+9dB or +12dB.
H : Gain value set by the menu is obtained. The set value is -3dB, +3dB, +6dB, +9dB
+12dB or +18dB.
Note:
the Output Select defaults to
the OCP in system
conguration with the CCU-980.
Note:
the Gain Select defaults to the
OCP in system conguration
with the CCU-980.
