SD1 Series Inverters Function Parameters
-34-
Function
code
Name Description Default Modify
2: SVPWM control
Suitable in applications
which do not need high
control accuracy, such as the load of fan and
pump. One inverter can drive multiple motors.
Note: Motor parameter autotuning is required
when vector mode is applied.
P00.01
Run command
channel
Select the run command channel of the inverter.
The control command of the inverter includes
start, stop, forward/reverse rotating, jogging and
fault reset.
0: Keypad ("LOCAL/REMOT" light off)
Carry out the command control by RUN,
STOP/RST on the keypad.
Set the multi-function key QUICK/JOG to
FWD/REVC shifting function (P07.02
=3) to
change the running direction; press RUN and
STOP/RST simultaneously in running state to
make the inverter coast to stop.
1: Terminal ("LOCAL/REMOT" flickering)
Carry out the running command control by the
forward rotation, reverse rotation and forward
jogging and reverse jogging of the multi-function
terminals
2: Communication ("LOCAL/REMOT" on);
The running command is controlled by the upper
monitor via communication
0 ○
P00.03
Max. output
frequency
The parameter is used to set the max. output
frequency of the inverter.
It is the basis of
frequency setup and the
acceleration/deceleration.
Setting range: P00.04~400.00Hz
50.00Hz ◎
P00.04
Upper limit of
running
frequency
The upper limit of the running frequency is the
upper limit of the output frequency of the inverter
which is lower than or equal to the maximum
frequency.
Setting range: P00.05~P00.03 (max. output
frequency)
50.00Hz ◎
