SD1 Series Inverters Function Parameters
-35-
Function
code
Name Description Default Modify
P00.05
Lower limit of
running
frequency
The lower limit of the running frequency is that of
the output frequency of the inverter.
The inverter
runs at the lower limit frequency if
the set frequency is lower than the lower limit.
Note: Max. output frequency ≥ u
pper limit
frequency ≥ lower limit frequency
Setting range: 0.00Hz~P00.04 (u
pper limit of the
running frequency)
0.00Hz ◎
P00.06
A frequency
command
selection
Note:
A frequency and B frequency cannot set
as the same frequency reference
method. The
frequency source can be set by P00.09.
0: Set via keypad digits
Modify the value of function code P00.10 (set the
frequency by keypad) to change
the frequency
by the keypad.
1: Set via AI1
(corresponding keypad
potentiometer)
2: Set via AI2 (corresponding terminal AI2)
3: Set via AI3 (corresponding terminal AI3)
Set the frequency by analog input terminals. SD1
series inverters
provide 3 channels analog input
terminals as the standard configuration, of which
AI1 is adjusting through analog potentiometer,
while AI2 is the voltage/current option
(0~10V/0~
20mA) which can be shifted by
jumpers, while AI3 is voltage input (-10V~+10V).
Note: When analog AI2 select 0~20mA input, the
corresponding voltage of 20mA is 10V.
100.0% of the analog input setting corresponds
to the maximum frequency (function code
P00.03) in forward direction and -100.0%
corres
ponds to the maximum frequency in
reverse direction (function code P00.03)
4: Set via high-speed pulse HDI
The frequency is set by high-
speed pulse
terminals. Goodrive20 series inverters
provide 1
high speed pulse input as the standard
configuration. The pulse frequency range is
0.00~50.00kHz.
100.0% of the high-speed pulse input setting
0 ○
P00.07
B frequency
command
selection
2 ○
