SD1 Series Inverters Function Parameters
-45-
Function
code
Name Description Default Modify
Inverter won't run,
and the system keeps in the
protection state until the running command is
canceled and enabled again.
1: The terminal running command is valid when
powering on. If the running command is detected
to be valid during powering on, the system will
start the inverter
automatically after the
initialization.
Note:
This function should be selected with
cautions, or serious result may follow.
P01.19
Hibernation
function setting
0x00~0x12
Ones place:
0: Run at the frequency lower limit
1: Stop
2: Sleep
Tens place: Stop mode
0: Coast to stop
1: Decelerate to stop
0x00 ◎
P01.20
Hibernation
wake-up
delay
time
This function code determines the
wake-up-from-
sleep delay time. When the
running frequency of the inverter
is lower than
the lower limit, the inverter enters standby.
When the set frequency exceeds the lower limit
one again and it lasts for the time set
by P01.20,
the inverter runs automatically.
Set frequency curve:
Running frequency curve:
Run Sleep
t2
t1
Run
Frequency
lower limit f0
Frequency f
Time t
Coast to
stop
t1 < P01.20, the VFD does not run
t1+t2 ≥P01.20, the VFD runs
Setting range: 0.0~3600.0s (valid when
P01.19=2)
0.0s ○
P01.21
Restart after
power off
This function can enable the inverter to start or
not after power off and power on.
0: Disabled
0 ○
