SD1 Series Inverters Function Parameters
-51-
Function
code
Name Description Default Modify
P03.12
Keypad setting
torque
Setting range: -300.0%~300.0%
(motor rated
current)
50.0% ○
P03.13
Torque
reference
filter
time
0.000~10.000s 0.100s ○
P03.14
Setting source
of upper-limit
frequency of
forward
rotation in
torque control
0: Set via keypad (P03.16 sets P03.14, P03.17
sets P03.15)
1: Set via AI1 (100%
corresponds to max.
frequency)
2: Set via AI2 (same as above)
3: Set via AI3 (same as above)
4: Set via pulse frequency HDI (same as above)
5: Set via Preset (same as above)
6: Set via Modbus
communication (same as
above)
7~9: Reserved
Note: setting method 1~
9, 100% corresponds to
the maximum frequency
0 ○
P03.15
Setting source
of upper-limit
frequency of
reverse
rotation in
torque control
0 ○
P03.16
Torque control
forward
rotation
upper-limit
frequency
keypad limit
value
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14;
P03.17 sets the value of P03.15.
Setting range: 0.00 Hz~P00.03 (the max. output
frequency)
50.00
Hz
○
P03.17
Torque control
reverse
rotation
upper-limit
frequency
keypad limit
value
50.00
Hz
○
P03.18
Upper-limit
setting of
electromotion
torque
This function code is used to select the
electromotion and braking torque upper-limit
setting source selection.
0: Set via keypad (P03.20 sets P03.18 and
P03.21 sets P03.19)
1: Set via AI1 (100% relative to three times of
0 ○
P03.19
Upper-limit
setting of
0 ○
