SD1 Series Inverters Function Parameters
-64-
Function
code
Name Description Default Modify
P05.45
Corresponding
middle setting
of AI3
Setting range of P05.34: P05.32~10.00V
Setting range of P05.35: -100.0%~100.0%
Setting range of P05.36: 0.000s~10.000s
Setting range of P05.37: 0.00V~P05.39
Setting range of P05.38: -100.0%~100.0%
Setting range of P05.39: P05.37~10.00V
Setting range of P05.40: -100.0%~100.0%
Setting range of P05.41: 0.000s~10.000s
Setting range of P05.42: -10.00V~P05.44
Setting range of P05.43: -100.0%~100.0%
Setting range of P05.44: P05.42~P05.46
Setting range of P05.45: -100.0%~100.0%
Setting range of P05.46: P05.44~10.00V
Setting range of P05.47: -100.0%~100.0%
Setting range of P05.48: 0.000s~10.000s
0.0% ○
P05.46
Upper limit of
AI3
10.00V ○
P05.47
Corresponding
setting of
the upper limit
of AI3
100.0% ○
P05.48
AI3 input filter
time
0.100s ○
P05.50
Lower limit
frequency of
HDI
0.000kHz~P05.52
0.000
kHz
○
P05.51
Corresponding
setting of HDI
low frequency
setting
-100.0%~100.0% 0.0% ○
P05.52
Upper limit
frequency of
HDI
P05.50~50.000kHz
50.000
kHz
○
P05.53
Corresponding
setting of upper
limit frequency
of HDI
-100.0%~100.0% 100.0% ○
P05.54
HDI frequency
input filter time
0.000s~10.000s 0.100s ○
