SD1 Series Inverters Function Parameters
-81-
Function
code
Name Description Default Modify
adjustments are valid
Tens place: frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting modes
2: Invalid for Preset speed when Preset speed
has the priority
Hundreds place: action selection during stopping
0: Setting is valid
1: Valid during running, cleared after stopping
2:
Valid during running, cleared after receiving
the stop command
Thousands place: ∧ / ∨ keys an
d analog
potentiometer integral function
0: The Integral function is valid
1: The Integral function is invalid
P08.43
Integral speed
ratio of keypad
potentiometer
0.01~10.00s 0.10s
○
P08.44
UP/DOWN
terminal control
setting
0x00~0x221
Ones place: frequency control selection
0: UP/DOWN terminals setting valid
1: UP/DOWN terminals setting invalid
Tens place: frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: All frequency modes are valid
2: When the Preset speed are priority, it is invalid
to Preset speed
Hundreds place: action selection when stop
0: Setting is valid
1: Valid in running, clear after stop
2: Valid in running, clear after receiving the stop
commands
0x000
○
P08.45
UP terminal
frequency
increment
integral
speed
ratio
0.01~50.00s 0.50 s
○
