Chapter 2 Specifications 9
10000 30' Minimum Chassis Specifications
RESISTANCE TO BENDING MOMENT
1,200,000 in-lb (138,255 kg-m)
14.2 cubic inches (232.7 cc)
75,000 ft-lb (10,369 kg-m)
GROSS VEHICLE WEIGHT RATING (2)
26,000 lb (11,793 kg) minimum
NOTES:
1 The Cab to Axle (CA) dimension varies based on the configuration of the body, crane, and
auxiliary equipment including welder decks. Make sure the CA is free and clear from
obstructions everywhere except between the frame rails.
2 The Gross Vehicle Weight Rating (GVW) is a minimum guideline. Contact IMT if you have
questions regarding your particular installation.
3 In addition to these specifications, heavy duty electrical and cooling systems are required. It
is recommended that the vehicle be equipped with an engine tachometer, auxiliary brake
lock, and power steering.
4 Weight distribution calculations are required to determine final axle loading.
5 All chassis, crane and body combinations must be stability-tested to ensure stability per
ANSI B30.5
Iowa Mold Tooling Co., Inc. reserves the right to change specifications and design without notice.
