Telescopic Crane Orientation
When an IMT telescopic crane is not factory-installed on a body, the crane is packed with the
boom oriented as it is built on a test stand to facilitate handling. Install the crane on the body
with boom pointing backward. Once the crane is bolted down, it can be rotated 180° (3.14
radians) to the boom rest.
400°
ROTATION
OUTLINE OF
TRUCK BODY
REAR OF
TRUCK
BOOM
REST
Crane Controls
IMT's telescopic cranes are controlled by radio remote controls. See the Telescopic Crane Radio
Remote System manual, IMT # 99905114, for complete details on the radio remote system.
