IMT 10000 User Manual

Chapter 4 Parts 51
99904925 Crane Assembly Parts List, Complete (See Parts List for Effectivity Dates)
MODEL 10000 CRANE ASSEMBLY (99904925) PARTS LIST
ITEM
PART#
DESCRIPTION
DETAILS
KIT #
QTY
1.
91723059
KIT-HARDWARE BASE &
MAST
1
2.
91723579
HARDWARE KIT-WINCH
MOUNT
1
3.
91723543
HARDWARE KIT-VALVEBANK
MOUNT
1
4.
51719413
HARDWARE KIT-CRANE
RADIO CONTROLS
1
5.
91723584
HARDWARE KIT
(effective through 05/22/13)
1
6.
91723601
HYDRAULIC KIT
A/R
6.
91725088
HYDRAULIC KIT
SINGLE PROPORTIONAL
A/R
7.
51723610
CORD REEL ASSEMBLY
30' WITH CONNECTOR
1
8.
51722956
CYLINDER
5.25/2.50 25.07S 45.52CCC
1
9.
51723604
CYLINDER ASSEMBLY
2.50/ 1.50 2.75/1.75 204.0S 144.6
1
10.
52718741
PIN (effective through 05/22/13)
MM 2.00 X 12.75 (11.94 )
2
11.
52722950
MAST WELDMENT
(effective through 05/22/13)
1
12.
52723022
WELDMENT-LOWER BOOM
(effective through 05/22/13)
7500/10000
1
13.
52723023
WELDMENT-1st STAGE EXT
BOOM
(effective through 05/22/13)
7500/10000
1
14.
52723024
WELDMENT-2nd STAGE EXT
BOOM
7500/10000
1
15.
52723030
PIN
M 1.50X 3.38
1
16.
52723036
PIN (effective through 05/22/13)
MM 2.00 X 9.00 (8.19 )
1
17.
52723058
WELDMENT- ANTI-TWO
BLOCK BRACKET
(effective through 04/17/13)
1
18.
52723060
WELDMENT-FLIP SHEAVE
(effective through 04/17/13)
9500/ 10000
1
19.
52723061
WELDMENT- SNATCH BLOCK
(effective through 03/04/13)
9500/ 10000
1
20.
52723563
WELDMENT-MAST
VALVEBANK BRACKET
(effective through 03/05/13)
1
21.
60030255
SHEAVE
9.00 NYLATRON GSM
1
22.
60030336
WEAR PAD-RC
.19 X 6.00 X 6.00
1
23.
60030337
WEAR PAD-ROUND
2.00 DIA X 1.00 DIA X 1.188 LG
2
24.
60030421
WEAR PAD-RC
.25 X 6.00 X 6 .00
1
25.
60030422
WEAR PAD-ROUND
2.00 DIA X .50 DIA X 1.69 L
1
26.
60030423
WEAR PAD-RC
0.25 X 2.25 X 6.00L
4
27.
60030424
CAP- ANTI-TWO BLOCK PIN
(effective through 04/17/13)
2
28.
60030425
WEAR PAD-ROUND
1.25 DIA X 0.50 DIA X 0.94L
2
29.
60030428
WEAR PAD-ROUND
2.0 0 DIA X .75 DIA X .72L
4
