IMT 10000 User Manual

7
In This Chapter
Model 10000 30' Specifications ................................................ 7
10000 30' Minimum Chassis Specifications .............................. 9
Dimensional Drawing ............................................................... 10
30' 10000 Crane Capacity ........................................................ 12
Model 10000 30' Specifications
GENERAL SPECIFICATIONS
CRANE RATING (Crane rating (ft-lb) is the rated load (lb)
multiplied by the respective distance (ft) from centerline of
rotation with all extensions retracted and lower boom in
horizontal position.)
75,000 ft-lb (10.4 tm)
HORIZONTAL REACH - FLIP SHEAVE UP (From
centerline of rotation)
30'-10" (9.4 m)
HORIZONTAL REACH - FLIP SHEAVE DOWN (From
centerline of rotation)
32'-1" (9.8 m)
HYDRAULIC EXTENSIONS (2)
102" & 102" (259 cm & 259 cm)
LIFTING HEIGHT (From base of crane)
30'-7" (9.3 m)
CRANE WEIGHT
2,480 lb (1,125 kg)
CRANE STORAGE HEIGHT
41.2" (104.7 cm)
MOUNTING SPACE REQUIRED (Crane base)
20" x 21" (50.8 cm x 53.3 cm)
OPTIMUM PUMP CAPACITY
10 -12 U.S gpm (37.9 - 45.4 l/min)
SYSTEM OPERATING PRESSURE
3,000 psi (206.8 bar)
CENTER OF GRAVITY
 Horizontal from Centerline of Rotation
54.5" (138.3 cm)
 Vertical from Bottom of Crane Base
21.38" (54.3 cm)
TIE-DOWN BOLT PATTERN (8 bolts)
14.75" x 14.75" (37.5 cm x 37.5 cm)
ROTATIONAL TORQUE
9,000 ft-lb (1.2 tm)
C HAPTER 2
Specifications

IMT 10000 Specifications

General

Brand	IMT
Model	10000
Category	Construction Equipment
Language	English
