IMT 10000 User Manual

Chapter 4 Parts 61
Lower Cylinder (51722956)
13
1
2
5
7
6
16
3
13
14
TE
ER
POLYGON BEARING
70055368
(2 PCS EACH END)
5.25"
40°
SPACER
BETWEEN
BEARINGS
4
9
8
45.52" RETRACTED
70.58" EXTENDED
±0.063"
Ø6" BORE
Ø5.25" BORE
Ø2.5" BORE
25.06" STROKE
Ø3.25" TYP
Ø2" TYP
COUNTERBORED
FOR BEARINGS
STAMP PART NUMBER
AND REVISION.
40°
13
EXTEND
PORT
RETRACT
PORT
TEST
PORT
9.5"
7
11 10
11
10
15
17
13
11
12
11
12
SEAL KIT # 94399133. INCLUDES ALL SEALS. SEALS CANNOT
PISTON SEALS
ITEM NO. DESCRIPTION QTY.
1 PISTON 1
2 WEAR RING 2
3 PISTON SEAL 1
4 O-RING 1
SECTION A-A
1
4
2
2 3
A
A
ITEM NO. QTY.
1 ROD BEARING 1
2 ROD SEAL 1
3 WIPER 1
4 O-RING 1
5 BACKUP RING 1
6 WEAR RING 1
ROD SEALS
DESCRIPTION
1
3
2
6
4 5
A
A
SECTION A-A
BE PURCHASED INDIVIDUALLY.
