20 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
Additional Installation Components, Non-IMT Body (93713748)
Chassis Wiring Harness (77441476 / 99905212)
IMT HARNESS
77441476
TO RECOMMENDED
SELECTOR SOLENOID
SELECTOR
SOLENOID
ENGINE
STOP
GROUND
ENGINE
SPEED
CRANE
HOURMETER
FLOOD
LIGHTS
BOOM
TO RECOMMENDED
SWITCHED 12V POWER
(NOT TO EXCEED 7 AMPS)
TO RECOMMENDED 12V CRANE
HOURMETER (12V LATCHING SIGNAL
WHEN LINK IS ESTABLISHED
BETWEEN RADIO AND TRANSMITTER)
TO RECOMMENDED OEM
12V SPEED CONTROL
TO BATTERY GROUND
TO RECOMMENDED
ENGINE KILL OPTION
30
85
87A
87
86
POWER
ENGINE
START
COMPRESSOR
ON
IN-LINE 5A FUSE
STOW
SIGNAL POWER
12V NORMALLY CLOSED
OUTPUT FROM BOOM STOW SENSOR
TO RECOMMENDED OEM
12V ENGINE START
IN-LINE
15A FUSE
12V NORMALLY OPEN OUTPUT
FROM BOOM STOW SENSOR
TO 12V SOURCE FOR BOOM
STOW SENSOR POWER
(12V MOMENTARY SIGNAL)
TO RECOMMENDED
COMPRESSOR ON
(12V LATCHING SIGNAL)
30
85
87A
87
86
TO 12V BATTERY
SOURCE
RECOMMENDED
USING PTO
GROUND SIGNAL
TO 12V
KEYED POWER
IGNITION
Filter (10 micron) (73052091)
Used on ship-out IMT telescopic cranes.
