IMT 10000 User Manual

Chapter 4 Parts 93
Horn Circuit (99905614)
86
30
87
85
87a
86
30
87
85
87a
86
30
87
85
87a
86
30
87
85
87a
STOW SENSOR NC (IMT CHASSIS HARNESS)
STOW SENSOR NO (IMT CHASSIS HARNESS)
SEE NOTES
NOTE: THIS MAY BE 12V OR GROUND
AND MOVE TO GRAY CONNECTOR ON RADIO (PIN 10)
REMOVE WIRE FROM CJ-401 POS C
AND MOVE TO GRAY CONNECTOR ON RADIO (PIN 9)
REMOVE WIRE FROM CJ-401 POS D
CRANE HARNESS 77441481 REV A
CHASSIS HARNESS - DOM 1-2 (77441444) DOM 3-4 (77441446)
STOW SENSOR NC (CRANE HARNESS)
STOW SENSOR NO (CRANE HARNESS)
PLEASE MAKE SURE TO SEE HOW HORN FUNCTIONS
BEFORE WIRING IN IMT HORN CIRCUIT
STOW SENSOR NC (IMT CHASSIS HARNESS)
STOW SENSOR NO (IMT CHASSIS HARNESS)
SEE NOTES
NOTE: THIS MAY BE 12V OR GROUND
GRAY CONNECTOR ON RADIO (PIN 10)
GRAY CONNECTOR ON RADIO (PIN 9)
CRANE HARNESS 77441481 REV B
CHASSIS HARNESS - DOM 1-2 (77441444) DOM 3-4 (77441446)
HORN OUTPUT (2)
HORN OUTPUT (1)
PLEASE MAKE SURE TO SEE HOW HORN FUNCTIONS
BEFORE WIRING IN IMT HORN CIRCUIT
