IMT 10000 - Base & Mast Assembly, Truck Mount (99904925) (See Parts List for Effectivity Dates); Base & Mast Assembly, Truck Mount (99904925)

30 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
Base & Mast Assembly, Truck Mount
(99904925) (See Parts List for Effectivity Dates)
NOTE: This base and mast assembly is shown as it if it were mounted on a truck.
1 64
1 67
1 67
1 66
164
167
65
211
233 4
3111
3111
41
51
34
41
250
115
80
81
77
77
77
6128
7128
59
6 7
5
NOTES (SEE REFERENCE NUMBER IN BOX):
1 TORQUE TO 280 FT-LB (38.7 KG-M)
2 USE RUST PREVENTATIVE ON SLIDE STOP, BEARING RACE, BOTTOM OF MAST AND TOP OF GEAR
BEARING.
3 APPLY BLUE THREAD LOCKER.
4 APPLY GEAR LUBE ON GEAR TEETH.
5 BASE AND MAST ASSEMBLY SHOWN AS MOUNTED ON THE TRUCK. VIEW A FROM BOTTOM OF
ROTATION ASSEMBLY.
6 PORT A
7 PORT B
