IMT 10000 User Manual

46 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
99904925 CRANE & WINCH ASSEMBLY
ITEM
PART #
DESCRIPTION
DETAILS
KIT #
QTY
56.
72063038
MACHINERY BUSHING
2.00 X14 GA NR
A/R
57.
72063039
MACHINERY BUSHING
2.00 X10 GA NR
A/R
68.
72062108
NUT
.50 -20 HEX CENTER LOCK
#2
4
70.
72602082
STUD (effective from 12/06/12)
.50-13(20)X2.75 NC(NF)
GR8STL
#2
4
79.
72034479
PLUG-PLASTIC
.50-13 X .50 UNC-2B
#5
2
84.
72060044
CAP SCREW
.38-16 X .75 HEX HEAD GR5 Z
#5
4
95.
72062104
NUT (effective from 03/05/13)
0.25-20 HEX NYLOCK
#5
10
98.
72063001
WASHER
(effective from 02/28/13)
.25 FLAT
#5
17
99.
72063003
WASHER
(effective from 04/10/13)
.38 FLAT
#5
9
103.
72063051
WASHER
.38 LOCK
#5
4
116.
72532355
ADAPTER
M STR/M JIC 6 6
#6
1
118.
72532357
ADAPTER
M STR/M JIC 6 8
#6
1
120.
72532359
ADAPTER
M STR/M JIC 10 8
#6
2
124.
72532700
ELBOW
M STR/90/ M JIC XL 6 6
#6
2
137.
60140838
COVER-VALVE BANK SIII
(effective from 03/05/13)
1
139.
72060004
CAP SCREW
(effective from 03/05/13)
0.25-20 X 1.00 HH GR5
#5
8
142.
60140916
PIN-TYPE NN 2.0 X 9.5
(effective from 05/22/13)
1
143.
71415016
KEEPER-PIN
(effective from 05/22/13)
0.62
3
144.
60140915
PIN-TYPE NN 2.0 X 13.75
(effective from 05/22/13)
3
145.
72063055
WASHER (effective from 05/22/13)
0.62 LOCK
3
146.
72060149
CAP SCREW
(effective from 05/22/13)
0.62-11 X 1.5 HH GR5
#5
3
REV Y 20140212
