96 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
Option-Winch Roller (99905055)
Kit 51723637
2
1
6
9
15
14
9
15
14
10
10
7
9
8
4
17
11
18
5
8
5
12
17
11
18
16
12
16
3
3
13
13
1
6
17
11
17
11
3"
(7.6 cm)
2.31"
(5.9 cm)
1"
(2.5 cm)
NOTES (SEE REFERENCE NUMBER IN BOX):
1 REPLACE EXISTING BAR ON WINCH WITH 60136607.
2 USE EXISTING BOLTS AS SHOWN.
99905055 PARTS LIST
ITEM
PART #
DESCRIPTION
DETAILS
KIT #
QTY
1.
71570825
WINCH-PLANETARY 6000 LB LINE
PULL
REF
2.
91723603
HARDWARE KIT-WINCH ROLLER
1
3.
52723094
MOUNTING BRACKET- WINCH
SWITCH
1
4.
52723095
ROLLER ASSEMBLY- WINCH
SWITCH
1
5.
60030439
SLEEVE-TYPE C
0.38X 0.62X.25
2
6.
60136607
WINCH PLATE-ROLLER BRACKET
1
7.
77041863
SWITCH-LIMIT
1
